Cov roj kub boiler yog tus cwj pwm los ntawm kev ua haujlwm siab, txuag hluav taws xob, kev nyab xeeb thiab yoog raws. Nws tau dav siv nyob rau hauv kev lag luam teb, tshwj xeeb tshaj yog nyob rau hauv lub sij hawm uas yuav tsum tau ib tug loj npaum li cas ntawm cov khoom cua sov, xws li tshuaj, tshuaj, tsev cov ntaub ntawv thiab lwm yam lag luam.
Cov roj kub boiler muaj cov yam ntxwv ntawm high thermal efficiency, thiab thermal efficiency ntawm cov roj kub boiler yog siab dua. Nyob rau tib lub sijhawm, nws tau nruab nrog kev tswj xyuas kev ua haujlwm thiab kev saib xyuas kev nyab xeeb, feem ntau yog nruab nrog kev tswj hwm kev ua haujlwm siab thiab kev saib xyuas kev nyab xeeb, uas tuaj yeem paub txog kev tswj tsis siv neeg, kev ua haujlwm yooj yim, thiab xyuas kom muaj kev nyab xeeb.
|
Yam khoom Hom |
WNS1.0-({2}}.8/1.0/1.25)-Y/Q |
WNS2.0-({2}}.8/1.0/1.25)-Y/Q |
WNS3.1.25-Y/Q |
WNS4.0-(1.0/1.25)-Y/Q |
WNS6.0-(1.25/1.6)-Y/Q |
WNS10.0-(1.25/1.6)-Y/Q |
|||||||
|
Rated Evaporation (t / h) |
1 |
2 |
3 |
4 |
6 |
10 |
|||||||
|
Rated Ua Haujlwm Siab (MPa) |
0.8/1.0/1.25 |
1.25 |
1.25 |
1.25/1.6 |
|||||||||
|
Saturated Steam Kub (degree) |
174/184/194 |
194 |
184/194 |
194/203 |
|||||||||
|
Cua sov |
Host (m2) |
22.7 |
46.2 |
69.5 |
92.87 |
133 |
225.2 |
||||||
|
Economizer (m2) |
8.65 |
13.1 |
22.08 |
26.2 |
41.5 |
65.8 |
|||||||
|
Chav qhov hluav taws xob (DN) |
50 |
80 |
100 |
125 |
150 |
||||||||
|
Dej qhov hluav taws xob (DN) |
40 |
50 |
50×2 |
||||||||||
|
Kev nyab xeeb Valve Chaw nres nkoj (DN) |
40 |
50 |
65 |
100 |
|||||||||
|
Kev haus dej (DN) |
25 |
40 |
50 |
||||||||||
|
Exhausted Gas Kub (degree) |
158/162 |
147/157 |
146/155 |
140/143 |
180/179.5 |
||||||||
|
Tsim Roj |
Lub teeb roj los yog ntuj |
||||||||||||
|
Kev siv roj (kg / h, Nm3 / h) |
67.1 |
80.5 |
133 |
160.5 |
201.5 |
242 |
268.6 |
323 |
401.8 |
481.5 |
683.5 |
653.5 |
|
|
Tsim Efficiency |
Ntau dua lossis sib npaug li 92 |
Ntau dua lossis sib npaug rau 92.1 |
Ntau dua lossis sib npaug rau 95.6 |
||||||||||
|
Packing Loj (mm) |
3660×1820×2100 |
4230×2150×2600 |
4830×2300×2700 |
5400×2400×2800 |
6060×2500×3080 |
7340×31800×3450 |
|||||||
|
Qhov hnyav (kg) |
5530 |
6600/6800 |
9800 |
11400/11800 |
17200/17800 |
30200/33700 |
|||||||
WNS series tsis siv neeg roj-tso roj (gas) chav boilers nrog nws cov kev siv hluav taws xob zoo thiab kev ua haujlwm yooj yim thiab kev saib xyuas tau dhau los ua cov cuab yeej siv tsis tau hauv ntau lub lag luam, cov pab pawg no feem ntau muaj cov kev xav tau siab rau ntau yam txheej txheem hauv kev lag luam, kev xav tau kub: kev siv hluav taws xob, kev saib xyuas kev nyab xeeb thiab kev paub txog ib puag ncig, thiab cov kev xav tau tshwj xeeb muaj cov cai nruj
Kev lag luam kev kawm: Nws tuaj yeem tsis yog tsuas yog muab cov dej kub rau cov tub ntxhais kawm siv xwb, tab sis kuj yog rau cov cua sov ntawm lub tsev kawm ntawv, tab sis kuj yog rau chav ntxhua khaub ncaws hauv tsev kawm ntawv thiab lwm qhov chaw los muab cov tub ntxhais kawm muaj kev nyob zoo thiab kev kawm ib puag ncig.
Kev lag luam cov khoom yas: muab cov pa txaus txhawb rau cua sov, ua ntej ua npuas ncauj, ziab thiab lwm yam txheej txheem. Kev lag luam khoom noj khoom haus: Raws li cov cuab yeej tseem ceeb thiab tseem ceeb hauv cov txheej txheem tsim khoom noj, boilers ua lub luag haujlwm tseem ceeb hauv ntau qhov txuas, xws li distillation, extraction, disinfection, ziab thiab kho. Kev lag luam khoom siv hauv tsev: Hauv kev tsim cov khoom siv hauv tsev, ntau lub zog hluav taws xob yuav tsum tau yaj thiab tsim cov khoom siv raw. Kev lag luam textile: Hauv kev ua cov khoom siv textiles, xws li luam ntawv thiab dyeing, yuav tsum muaj qhov kub thiab txias ruaj khov los tuav cov ntaub.
WNS series tsis siv neeg roj-tso roj (gas) chav boiler kev lag luam, txuag hluav taws xob, txo tus nqi qis: hluav taws xob cua sov cheeb tsam, qhov chaw loj combustion, tag nrho combustion, ntxiv dag zog rau cov cua sov hloov, thermal efficiency siab tshaj lub teb chaws tus qauv, tus nqi qis. Zoo heev, tsis muaj kev txhawj xeeb tom qab muag: lub puab liner tau txais tshwj xeeb boiler steel phaj thiab seamless steel yeeb nkab, tsis siv neeg vuam vuam, thiab los ntawm kev kuaj tsis muaj kev puas tsuaj, lub cev sib thooj dej siab ntsuas, tag nrho corrugated lub ntsiab rauv rauv tsim muaj zoo thermal yooj, zoo. nqus thermal expansion, tsis txhob muaj kev ntxhov siab, lub plhaub stainless hlau los xyuas kom meej lub neej kev pab cuam. Kev ua haujlwm ntse, siv tau yooj yim: microcomputer tswj, hluav taws xob txawv teb chaws, dej tsis txaus, overpressure, dej timeout, burner flameout thiab lwm yam kev tiv thaiv ntau yam; Kev khiav haujlwm, chav siab, chav ntsuas kub, cov ntaub ntawv ceeb toom tuaj yeem tso tawm ntawm lub vijtsam LCD, txuag lub sijhawm thiab kev ua haujlwm, txuag cov nqi zog feem ntau. Kev tiv thaiv ib puag ncig thiab huv, tsis muaj emissions, raws li lub teb chaws tus qauv.
